Fiatagri 40-90 Turbo 160-90 Turbo Farm Tractors Repair Manual
Fiatagri 115-90 Turbo, 130-90 Turbo, 140-90 Turbo, 160-90 Turbo, 180-90 Turbo Farm Tractors Service Repair Manual
Service Repair Manual Contains:
General
00 – Specifications
10 – Engine: Specifications and datas
11 – Engine: Description – Performance data – Removal – Installation
12 – Engine: Engine block – Cylinder head
13 – Engine: Valve gear
14 – Engine: Crankgear
15 – Engine: Fuel System
16 – Engine: Lubrication system
17 – Engine: Cooling system
20 – Power Train: Specifications and data
21 – Power Train: Removal and Installation
22 – Power Train: Master Clutch
23 – Power Train: Transmission and Splitter
23 – Power Train: Power Shift transmission
24 – Power Train: Creeper – Mechanical reverser
25 – Power Train: Bevel drive and differential
26 – Power Train: Brakes
27 – Power Train: Final drives
28 – Power Train: Power take-off
30 – Front Axle – Steering: Specifications and data
31 – Front Axle – Steering: Front axle
32 – Front Axle – Steering: Power Steering
40 – Front Wheel Drive: Specifications and data
41 – Front Wheel Drive: Live front axle
42 – Front Wheel Drive: Drive shafts – Axle drive
50 – Hydraulic lift Unit: Specifications and data
51 – Hydraulic lift Unit: Lift
52 – Hydraulic lift Unit: Lift pump
53 – Hydraulic lift Unit: Implement attachment
54 – Hydraulic lift Unit: Remote control valves
60 – Electrical System – Specifications and data
90 – Service Tools.
Fiatagri 40-90 Turbo 160-90 Turbo Farm Tractors Repair Manual
If you are looking for a service checklist for a Fiatagri 115-90 Turbo tractor, here is a general list of tasks that you may want to consider:
1. Engine Service:
– Check and replace the engine oil and oil filter as per the manufacturer’s recommendations.
– Inspect and replace the air filter if necessary.
– Check the coolant level and condition and top up or replace coolant as needed.
– Inspect the fuel filter and replace it if required.
– Check and adjust the fan belt tension.
– Inspect and clean the radiator and cooling system.
2. Transmission and Clutch Service:
– Check the transmission oil level and condition, and top up or replace as necessary.
– Inspect and adjust the clutch pedal free play and engage point.
– If equipped, check and adjust the clutch release bearing.
– Inspect the transmission components for any leaks or damage.
3. Hydraulic System Service:
– Check the hydraulic oil level and condition, and top up or replace as needed.
– Inspect hydraulic hoses and connections for any leaks or damage.
– Check and adjust hydraulic system pressures if required.
– Inspect and replace hydraulic filters as recommended by the manufacturer.
4. Electrical System Service:
– Check the battery condition, terminals, and connections.
– Inspect the wiring harness for any signs of wear or damage.
– Test the operation of lights, gauges, and other electrical components.
5. Steering and Suspension Service:
– Inspect and lubricate steering components.
– Check the steering fluid level and condition.
– Inspect suspension components for wear or damage.
6. Brake System Service:
– Inspect brake pads, shoes, and discs for wear.
– Check brake fluid level and condition, and top up or replace as needed.
– Inspect brake lines and connections for leaks or damage.
7. Chassis and Frame Service:
– Inspect the overall condition of the tractor’s chassis and frame.
– Check for any signs of cracks, rust, or other structural issues.
– Lubricate pivot points and grease fittings as recommended.
8. Tire and Wheel Service:
– Inspect tires for wear, cuts, or punctures.
– Check tire pressure and adjust if necessary.
– Inspect wheels for any damage or loose bolts.
