John Deere 130G (SN. from D040001) Crawler Excavators Repair Manual TM12557
The John Deere 130G (SN. from D040001) Crawler Excavators Repair Manual TM12557 provides repair and maintenance information for the 130G crawler excavator with Tier 3, Stage IIIA emission standards. It covers safety procedures, torque values, track systems, axle shafts, bearings, reduction gears, and hydraulic systems. Additional sections include engine removal and installation, cooling, intake and external fuel supply systems, damper drive components, and frame installation. The manual also addresses the operator station, sheet metal, optional backfill blade, excavator components, swing systems, and dealer-fabricated tools.
Specifications: SM
- Brand: John Deere Excavators
- Type of Document: Repair Manual
- Type of Equipment: Crawler Excavator
- Model: 130G
- Manual Number: TM12557
- Emission Standards: Tier 3, Stage IIIA
- Serial Number: 040001-
- All Serial Number: 040001-
- All PIN: 1FF130GX__D040001-
- Language: English
- Format: PDF
Details:
Table of Contents
Introduction
- Foreword
- Technical Information Feedback Form
General Information
- Safety
- Torque Values
Tracks
- Track System
Axles, Differentials, and Suspension Systems
- Axle Shaft, Bearings, and Reduction Gears
- Hydraulic System
Engine
- Removal and Installation
Engine Auxiliary System
- Cooling Systems
- Intake System
- External Fuel Supply Systems
Damper Drive (Flex Coupling)
- Elements
Frame or Supporting Structure
- Frame Installation
- Chassis Weights
Operator`s Station
- Removal and Installation
- Operator Enclosure
- Seat and Seat Belt
- Heating and Air Conditioning
Sheet Metal
- Hood and Engine Side Shields
Blade (Backfill) (If Equipped)
- Blades
- Hydraulic System
Excavator
- Buckets
- Frames
- Hydraulic System
Swing or Pivoting System
- Mechanical Drive Elements
- Hydraulic System
Dealer Fabricated Tools
- Dealer Fabricated Tools
