John Deere 690CR Excavators with All Terrain Wheeled Undercarriage Technical Manual TM1329
The John Deere 690CR Excavators with All Terrain Wheeled Undercarriage Technical Manual TM1329 provides technical information for the 690CR wheeled excavator, covering general information, wheels and tires, axles and suspension, engine components, auxiliary engine systems, and electrical systems.
Specifications: SM
- Brand: John Deere Excavators
- Type of Document: Technical Manual
- Type of Equipment: Wheeled Excavator
- Model: 690CR
- Manual Number: TM1329
- Language: English
- Format: PDF
Details:
Table of Contents
GENERAL INFORMATION
- Introduction and Safety Information
- Specifications
- Torque Values
- Fuels and Lubricants
- Predelivery and After-Sale Inspection
- Tools and Materials
- Inspection Procedures
- Inspection Checklist Example
- Product Inspection Manual (PIM)
- Checklist
WHEELS
- Wheels & Tires
AXLES AND SUSPENSION SYSTEMS (PROPEL )
- Axle and Suspension
- Axle Shaft. Bearings, and Reduction Gears
- Hydraulic System
ENGINE
- Removal and Installation
- Crankshaft & Main Bearings
- Camshaft & Valve Actuating Means
- Connecting Rods and Pistons
- Cylinder Block
- Oiling System
ENGINE- Continued
- Ventilating System
- Cylinder Head and Valves
- Exhaust Manifold
- Fuel Injection System
- Intake Manifold
- Turbocharger
- Water Pump
- Thermostats, Housings and Water Piping
- Oil Cooler
- Fuel Transfer Pump
- Starting Motor and Fastenings
- Flywheel. Housing and Fastenings
ENGINE AUXILIARY SYSTEM
- Cold Weather Starling Aid
- Cooling Systems
- Speed Controls
- Intake System
- External Exhaust Systems
- External Fuel Supply Systems
ELECTRICAL SYSTEMS
- Batteries. Support and Cables
- Alternator. Regulator , and Charging System Wiring
- Wiring Harness and Switches
- Instruments and Indicators
