John Deere 3033R 3039R 3046R Tractor Technical Manual TM164719
The John Deere 3033R, 3039R, and 3046R Tractor Technical Manual provides detailed service, repair, diagnostic, and troubleshooting information for these compact utility tractors. Designed for professional technicians, mechanics, and equipment owners, this manual includes step-by-step repair procedures, specifications, system tests, adjustments, and component information.
Specifications: SM
- Brand: John Deere
- Type of Document: Technical Manual
- Type of Equipment: Tractor
- Model: 3033R, 3039R, 3046R
- Serial Number: LL000001-
- Manual Number: TM164719
- Language: English
- Format: PDF
Details:
Table of Contents
Introduction
- Foreword
General Information
- Safety
- General References
- Technical Specific References
- Fuel and Lubricants
- Serial Number Locations
Engine Repair
- Engine
- Cooling System
Fuel, Air Intake, and Exhaust Repair
- Fuel
- Air Intake
Electrical Repair
- Electrical Connector Repair
- Battery, Starter, and Alternator
- Electrical System Components
Drive Systems and Transmission Repair
- Power Train
- Mechanical Front Wheel Drive
- Differential
- PTO
Steering Repair
- Steering
Brake Repair
- Brake
Hydraulics Repair
- Hydraulic Pump and Filter
- Rockshaft
- Range Control and Three Point Hitch
- Selective Control Valve
- Hydraulic Lines
Miscellaneous Repair
- Hood and Side Panels
- Fenders
- Wheels
Cab/Open Operator’s Station Repair
- Seat and Support
- Control Console
- Roll-Gard
- Cab Components
- Open Operator Station Components
Diagnostic Trouble Codes
- General References
- Instrument Cluster Control (ICC) Diagnostic Trouble Codes
- Engine Control Unit (ECU) Diagnostic Trouble Codes
- Power Train Hydrostatic (PTH) Control Unit Diagnostic Trouble Codes
- Selective Control Valve (SCV) Control Unit Diagnostic Trouble Codes
Observable Symptoms and System Diagnostics
- General References
- Engine System Diagnostics
- Fuel, Air Intake, Exhaust, and Cooling System Diagnostics
- Electrical System Diagnostics
- Electronic Control Unit System Diagnostics
- Drive Systems and Transmission System Diagnostics
- Steering System Diagnostics
- Brakes System Diagnostics
- Hydraulic System Diagnostics
- Cab/Open Operator’s Station System Diagnostics
Engine Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Schematics
- Component and Connector Information
- Tests and Adjustments
Fuel, Air Intake, Exhaust, and Cooling Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Component and Connector Information
- Tests and Adjustments
Electrical General and Theory of Operation
- General References
- Electrical Theory of Operation
Electrical Schematics
- General References
- Starting and Charging (SE1)
- Cab Lighting-Without License Light (SE2A)
- Cab Light-With License Light (SE2B)
- OOS Lighting-Without License Light (SE2C)
- OOS Light-With License Light (SE2D)
- Instrument Control Cluster (ICC) (SE3)
- Engine Control Unit (ECU) (SE4)
- Transmission Control Unit (TCU) (SE5)
- Kits (SE6)
- Cab (SE7)
- EH Selective Control Valve (SCV) Controller (SE8)
Electrical Components and Connectors
- General References
- Electrical Assemblies, Modules, and Control Units
- Sensors
- Resistors/Condensors/Capacitors
- Memory and Binary Devices
- Lights
- Fuses
- Charging
- Monitoring/Warning Devices
- Relays
- Motors
- Switches
- Diodes
- Wiring Harnesses – NA
- Wiring Harnesses – EU
- Interconnects
- Solenoids and Electrically Actuated Mechanical Devices
- Ground Points
Electrical Tests and Adjustments
- General References
- Tests and Adjustments
Electronic Control Units
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Component and Connector Information
- Test and Adjustments
- Instrument Cluster Control (ICC)
- Engine Control Unit (ECU)
- Power Train Hydrostatic (PTH)
Drive System and Transmission Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Schematics
- Component and Connector Information
- Tests and Adjustments
Steering Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Schematics
- Component and Connector Information
- Tests and Adjustments
Brake Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Component and Connector Information
- Tests and Adjustments
Hydraulics Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Schematics
- Component and Connector Information
- Tests and Adjustments
Cab/Open Operators Station Operation, Test, and Adjustments
- General References
- Calibrations, Preliminary Checks and Operational Checks
- Theory of Operation
- Component and Connector Information
- Tests and Adjustments
Service Tools
- General References
- Service Tools
- Dealer Fabricated Tools
- Section 240A
- Section 240B
- Section 240C
- Section 240D
